The SeisBrace Design Tool - Seismic Bracing Zone of Influence Calculation software - helps calculate Cp following NFPA 13 (2016) and the referenced ASCE7 Standard.
It offers all new functionality and includes the entire brand of Afcon seismic bracing products. The product includes new “Prying factors” in NFPA 13 (2016) for concrete anchors for seismic brace structural attachment;
The product can calculate: lateral braces, riser braces in both wall and corner conditions and brace loads at wide or narrow angles.
The product also includes alternate components, calculated and included in submittal to allow last-minute field changes of material
